| Model name |
SNS850 |
| Power Consumption |
850W (BGR:800W + FR=50W) |
| Heat dissipation structure |
PTX™ (Plate Thermal Exchanger) |
| PPF (umol/s) |
400-700nm / 2400~3040 @ 800W |
| PE(umol/J) |
400-700nm / 3.0 ~ 3.8 |
| Light distribution type |
Normal / Wide |
| Input voltage |
200 ~ 400Vac |
| Input current |
Max 3.0A(@380Vac) |
| Module size (mm) |
961 × 154 × 127 mm |
| Weight (Driver excluded) |
4.4kg |
| Material(Body) |
AL6063 + PTX + SUS |
| IP rating |
IP66 |
| Operating Temperature |
0°C ~ 40°C |
| Warranty |
5 Years (12 hours usage per day) |
|
